Dab tsi yog 17-7ph Stainless Hlau Chev?
Tso lus
Puas yog koj tab tom nrhiav rau qib siab -kev ua haujlwm stainless hlau uas sib txuas lub zog, kev tiv thaiv corrosion, thiab hardness zoo heev? Yog tias muaj, 17-7PH stainless hlau coils tej zaum yuav yog qhov koj xav tau . 17-7PH stainless hlau boasts superior mechanical zog thiab versatility, ua rau nws lug siv nyob rau hauv industries xws li aerospace, tshuaj, thiab precision engineering.
Dab tsi yog 17-7ph stainless hlau kauj?
17-7PH stainless hlau kauj yog siab -lub zog, nag lossis daus- hardening semi- austenitic stainless hlau (UNS S17700 / AISI 631) muab rau hauv daim ntawv coil. Nws muaj zog zoo, hardness, zoo corrosion kuj (ze rau hom 304), zoo formability (tom qab annealing), thiab tsawg deformation tom qab kev kho cua sov. Tsis zoo li cov pa hlau tsis zoo, 17-7PH tuaj yeem ncav cuag lub zog kawg tom qab kev laus kho, ua rau nws yog ib qho khoom siv zoo tshaj plaws rau cov dej ntws, cov khoom siv hauv aerospace, thiab cov ntawv thov kev ntxhov siab.
Peb Cov Khoom
Yog tias koj xav paub ntau ntxiv thiab cov nqi ntawm cov khoom, thov hu rau peb hauv lub sijhawm! Email:info@gneestainless.com
Tshuaj muaj pes tsawg leeg ntawm 17-7PH Stainless hlau
| Lub ntsiab | C | Mn | Si | Cr | Ni | Fe | Al | Nb |
|---|---|---|---|---|---|---|---|---|
| % | Tsawg dua los yog sib npaug li 0.07 | Tsawg dua lossis sib npaug li 1.00 | Tsawg dua lossis sib npaug li 1.00 | 16.0–18.0 | 6.0–7.0 | Tshuav | 0.20–0.80 | 0.40–0.70 |
Lus Cim: Kev sib xyaw yuav txawv me ntsis raws li cov qauv thoob ntiaj teb (ASTM A693, JIS SUS630, thiab lwm yam).
Mechanical Properties
| Khoom | Kev kho mob | Hnub nyoog (H900) |
|---|---|---|
| Tensile zog (MPa) | 930 | 1380 |
| Yield zog (MPa) | 620 | 1240 |
| Elongation (%) | 18 | 12 |
| Hardness (HRB) | 88 | 42 HRC |
17-7ph stainless hlau kauj daim ntawv thov
Aerospace qhov chaw thiab cov khoom siv
Springs thiab precision fasteners
Cov khoom siv tshuaj ua haujlwm
Cov cuab yeej kho mob thiab cov cuab yeej phais
Dab tsi yog qhov txawv ntawm 17-7PH thiab 17-4PH stainless hlau?
Thaum ob qho tib si yog nag lossis daus hardening stainless hlau, 17-7PH muaj kev qaug zog ntau dua thiab zoo dua kev ntxhov siab corrosion cracking tsis kam, ua rau nws zoo tagnrho rau qhov chaw muaj kev ntxhov siab.
17-7PH puas tuaj yeem welded?
Yog lawm, nws tuaj yeem welded siv cov txheej txheem txheej txheem, tab sis tom qab -weld kev kho cua sov yog pom zoo kom rov qab muaj zog thiab corrosion kuj.
Dab tsi thicknesses muaj rau 17-7PH stainless hlau coils?
Hom thickness ranges ntawm 0.2 hli mus rau 4.0 hli, nrog customizable dav rau ntau yam kev xav tau.
Ntawm Gnee, peb muab siab - zoo 17-7PH stainless hlau coils uas ua tau raws li ASTM, JIS, GB, thiab EN cov qauv. Peb cov khoom tau ntawv pov thawj los ntawm ISO, SGS, thiab BV, kom ntseeg tau kev ntseeg siab rau aerospace, tshuaj, thiab precision engineering daim ntaub ntawv. Peb muab cov kev cai txiav, slitting, polishing, thiab kev kho deg kom tau raws li koj cov lus qhia meej.
Txhim kho koj qhov kev ua tau zoo niaj hnub no nrog hwm 17-7PH stainless hlau kauj los ntawm Gnee - tsim kom muaj zog, kav ntev, thiab precision.
Nyem mus download tau 17-7ph cov ntaub ntawv cov ntaub ntawv.
