ASTM B163 UNS N04400 Alloy Thaum tshav kub kub Exchanger Tube
Txuj: ASTM B163 / ASME SB163
Khoom Qib: UNS N04400 (Monel® 400)
Kev tsim khoom: Cold Drawn, Seamless, Solution Annealed
Sab nraud txoj kab uas hla (OD): 6.35–76.2 mm (1/4 "–3")
Phab ntsa Thickness (WT): 0.5-4.19 hli
Length: Txog 18 m lossis Custom Fixed Length
Nto tiav: Annealed (AP), Pickled, Bright Annealed (BA), Polished
Xaus Xaus: Plain End (PE), Beveled End (BE)
Tube Hom: Ncaj Tube, U Tube, Kub Exchanger Tube, Condenser Tube
Cov ntaub ntawv soj ntsuam:EN 10204 3.1 / 3.2 MTC, SGS, BV, TUV Muaj
Packing: Yas Caps, Woven Hnab, Ntoo Case, Export Seaworthy Packing
Xa E-mail:info@gneestainless.com
Tel:+8615824687445
Hauj lwm lawm
Gnee Steel (Tianjin) Co., Ltd. yog ib qho ntawm cov kws tshaj lij thiab cov neeg muag khoom ntawm astm b163 uns n04400 alloy kub exchanger raj hauv Suav teb. Nrog kev paub ntau, peb zoo siab tos txais koj rau cov lag luam wholesale customized astm b163 uns n04400 alloy kub exchanger raj los ntawm peb lub hoobkas. Rau nqe kev sab laj, tiv tauj peb.
ASTM B163 specification yog dab tsi?
ASTM B163 yog ib qho kev lag luam khoom siv uas npog seamless npib tsib xee alloy tubing -nrog rau sab nraud txoj kab uas hla tsis tshaj 76.2 mm (3 ntiv tes)- npaj rau kev siv hauv condensers thiab heat exchangers, thiab nws qhia meej txog cov kev cai nruj txog cov tshuaj muaj pes tsawg leeg, txhua yam khoom, dimensional tolerances, hardness, thiab nonde.
ASME SB 163 N04400 Tubing Supplier thiab Chaw tsim tshuaj paus
Nrog tshaj 18 xyoo ntawm kev xa tawm thoob ntiaj teb, GNEE muab cov nickel alloy kub exchanger raj rau cov neeg siv khoom hauv ntau tshaj 80 lub teb chaws thoob ntiaj teb. Peb lub lag luam nthuav dav cov tebchaws thiab thaj chaw suav nrog Asmeskas, Canada, Lub Tebchaws Yelemees, Spain, Netherlands, Ltalis, Qaib ntxhw, Kaus Lim Qab Teb, Nyab Laj, Is Nrias teb, Pakistan, Saudi Arabia, UAE, South Africa, thiab Brazil.
ASTM B163 UNS N04400 alloy tshav kub exchanger tube muab los ntawm GNEE yog seamless npib tsib xee- tooj liab alloy raj tshwj xeeb tsim rau condensers thiab tshav kub exchangers. Tsim los ntawm siab- zoo, nqus tsev- melted npib tsib xee alloy billets, nws undergoes txheej txheem xws li kub extrusion, multi-dhau txias drawing / txias dov, tshuaj annealing, precision sizing, straightening, kaj annealing, pickling thiab passivation, thiab zaum kawg soj ntsuam.
Muaj qhov tsawg kawg nkaus ntawm 63% npib tsib xee (Ni) thiab 28% - 34% tooj liab (Cu), nws nthuav tawm tus nqi corrosion tsawg dua 0.025 hli / xyoo hauv dej hiav txwv ntws thiab tiv taus pitting, crevice corrosion, thiab chloride-induced stress corrosion cracking. Piv nrog rau cov hlau tsis muaj steel thiab cov tooj liab alloys, nws muaj qhov tseem ceeb ntev -lub sijhawm ua haujlwm zoo.
Tom qab annealing, nws lub zog tensile ntau dua los yog sib npaug rau 480 MPa, lub zog tawm los yog ntau dua lossis sib npaug rau 170 MPa, thiab elongation ntau dua 35%. Nws tuav cov neeg kho tshuab muaj zog thoob plaws qhov kub thiab txias xws li cov xwm txheej cryogenic mus txog 540℃(1000℃F). Qhov no ua kom muaj txiaj ntsig zoo rau kev siv hluav taws xob hloov pauv lub neej thiab txo cov khoom siv tu lub sijhawm, ua rau nws siv dav hauv marine desalination, petrochemicals, chlor-alkali kev lag luam, thiab fais fab nroj tsuag feedwater cua sov tshuab.
Peb txhawb kev cai sab nraud diameters (6 mm–114 mm) thiab phab ntsa thicknesses (0.8 mm–12 mm). Raws li cov neeg siv khoom xav tau kos duab, peb muab kev cai -ntev ncaj raj lossis U- cov kev pabcuam kev ua cov raj khoov. Raws li cov neeg siv khoom thov, peb tuaj yeem muab EN 10204 3.2 daim ntawv pov thawj nrog rau thib peb - cov kev pabcuam tshuaj xyuas los ntawm SGS, BV, TÜV, thiab lwm yam.
ASME SB163 / B165 Monel 400 Chemical Compositon:
| QIB | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | Max 0.30 Nws | 2.00 Nws | 0.5 Max | 0.24 Max | 28.0-34.0 | 2.50 Max | 63.00 Nws |
Qib sib npaug rau Monel 400 Seamless Tubes:
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.436 | N04400 | NWS 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NR-30 M | NiCu 30 Fe |
ASME SB163 / B165 Monel 400 Mechanical Properties:
|
rade |
Qhov xwm txheej |
Tensile zog, min, psi (MPa) |
|
|
|||||
|
MONEL 400 (UNS N04400) |
Annealed, 5 in.(127mm) sab nraud txoj kab uas hla thiab uner |
70,000(480) |
28,000(195) |
35% |
|||||
|
Annealed, Tshaj 5 in.(127 mm) sab nraud txoj kab uas hla |
70,000(480) |
25,000(170) |
35% |
||||||
|
Kev ntxhov siab -Txuag, Txhua qhov ntau thiab tsawg |
85,000(585) |
55,000(380) |
15% |
||||||
ASTM B163 UNS N04400 Tube Temperature Range
| Khoom | Tus nqi |
|---|---|
| Ua haujlwm kub | -200℃txog 550℃(Kev Pabcuam Hom) |
| Oxidation Resistance | Zoo mus txog kwv yees li 550 degree |
| Corrosion Resistance | Zoo heev tiv thaiv dej hiav txwv, hydrofluoric acid, alkalis, thiab chloride ib puag ncig |
|
Dimension Permissible nyob rau sab nraud txoj kab uas hla, Phab ntsa Thickness thiab Length ntawm ASTM B163 Standard Condenser thiab Kub Exchanger |
|||||||||
|
Permissible Variations |
|||||||||
|
Khoom siv |
Nominal Outside Diameter, nyob rau hauv.(mm) |
Sab nraud txoj kab uas hla, in.(mm) |
Phab ntsa Thickness,% Phab ntsa nruab nrab |
Phab ntsa Thickness,% Tsawg phab ntsa |
Length, hli (mm) |
||||
|
UNS N02200, UNS N02201, UNS N04400 |
Tshaj |
Hauv qab |
Tshaj |
Hauv qab |
Tshaj |
Hauv qab |
Tshaj |
Hauv qab |
|
|
1/2 txog 5/8 (12.7 txog 15.9), excl |
0.005(0.13) |
0 |
12.5 |
12.5 |
25 |
0 |
1/8 (3.2) |
0 |
|
|
8/5 txog 1-1/2 (15.9 txog 38.1), incl |
0.005(0.13) |
0.005(0.13) |
10 |
10 |
20 |
0 |
|||
|
Tshaj 1-1/2 txog 3 (38.1 txog 76.2), incl |
0.010(0.25) |
0.010(0.25) |
10 |
10 |
22 |
0 |
Hauv qab 30 ft (9.1m) ↑ |
||
Daim ntawv thov ntawm ASTM B163 UNS N04400 Alloy Tube:
Marine engineering thiab seawater piping systems;
Cov cuab yeej siv tshuaj thiab petrochemical;
Feedwater heaters thiab heat exchangers nyob rau hauv lub hwj chim tsim.
Yog tias koj tab tom ua haujlwm ntawm ib qhov project, qhia rau kuv paub: Dab tsi yog qhov yuav tsum tau ua (nruab txoj kab uas hla thiab phab ntsa tuab) yog dab tsi? Qhov kev khiav hauj lwm kub thiab dej nruab nrab yog dab tsi?Kuv tuaj yeem pab txheeb xyuas yog tias ASTM B163 Monel 400 yog qhov zoo tshaj plaws haum lossis pab xam cov kev ntsuas siab.
Dab tsi yog qhov txawv ntawm ASTM B163 thiab ASTM B165?
Qhov sib txawv tseem ceeb yog lawv qhov kev thov thiab cov peev txheej: ASTM B163 qhia meej seamless npib tsib xee thiab npib tsib xee alloy raj rau condensers thiab tshav kub exchangers, thaum ASTM B165 npog txias- ua haujlwm seamless nickel- tooj liab alloy (Monel 400) yeeb nkab thiab raj rau kev pabcuam dav dav.
ASTM B163 UNS N04400 Alloy Tube nqi ib kg
ASTM B163 UNS N04400 (Monel 400) alloy tube feem ntau raug nqi ntawm $ 10 thiab $ 40 ib kg, nyob ntawm qhov kev txiav txim ntim, kev tsim khoom (seaamless lossis welded), thiab qhov ntev. Cov nqi lag luam wholesale qee zaum tuaj yeem pib qis li $ 3,000 txog $ 12,500 ib tuj ($ 3 txog $ 12.50 toj ib kg), thaum lub khw muag khoom tshwj xeeb ntev lossis me me -batch seamless condenser raj scale siab dua.
Kev Tswj Xyuas Zoo
Ua ntej tawm hauv lub Hoobkas, txhua pawg ntawm cov khoom tau dhau 100% eddy tam sim no kuaj (ECT), hydrostatic testing, PMI (Positive Material Identification), tshuaj lom neeg muaj pes tsawg leeg, ntsuas tensile, flattening test, flaring test, hardness test, dimensional inspection, and despection inspection to ensure full compliance with ASTM B163 technical specifications.
High - ntim khoom thauj zoo
Plastic Pipe Caps: Lub kaus mom yas plua plav ruaj ntseg (feem ntau yog xiav) yuav tsum haum rau ob qho kawg ntawm txhua lub yeeb nkab kom tsis txhob muaj plua plav, ya raws, thiab cov khoom txawv teb chaws, thiab tiv thaiv cov beveled los yog qhov kawg ntawm kev puas tsuaj.
Kev tiv thaiv tus kheej:
Plastic Tes Tsho / Stretch Wrap: Txhua lub yeeb nkab yuav tsum tau muab tso rau hauv ib lub tes tsho yas los yog npuas npuas.
Separators / Cushioning: Ntoo spacers lossis EPE ua npuas ncauj cushioning txheej yuav tsum muab tso rau ntawm cov yeeb nkab txheej hauv cov ntoo crate kom tiv thaiv cov kav dej hauv qab los ntawm kev sib tsoo.
Reinforced Fumigation-Free Wooden Cases (Plywood Cases): Ntoo rooj plaub yog tib txoj kev pom zoo rau kev ntim khoom rau siab -value alloy kav. Lub hauv paus ntawm rooj plaub yuav tsum tau ntxiv dag zog kom yooj yim rau kev tuav forklift.
FAQ
Q: Koj puas tuaj yeem tsim U-khoov raj?
A: Yog. Monel 400 muaj ductility zoo heev, ua rau nws zoo tagnrho rau U- dabtsi yog khoov. Peb ua dabtsi yog khoov raws li ASTM A556/B163 tus qauv thiab siv cov kev ntxhov siab tsim nyog-kev kho cua sov rau cov ntu khoov.
Q: Vim li cas Monel 400 ho kim dua stainless hlau?
A: Qhov no feem ntau yog vim nws cov ntsiab lus nickel siab (tshaj 63%); npib tsib xee yog cov hlau muaj txiaj ntsig uas raug cuam tshuam rau tus nqi hloov pauv hauv ntiaj teb kev ua lag luam. Tsis tas li ntawd, Monel 400 yog qhov nyuaj rau kev ua haujlwm, xav tau cov cuab yeej tshwj xeeb thiab cov cuab yeej tsim khoom.
Q: Lub sij hawm txhuas txhuas rau cov raj no yog dab tsi?
A: Yog tias cov khoom lag luam puag ncig muaj, lub sijhawm ua haujlwm feem ntau yog 45-60 hnub.
Rau ntxiv - cov raj ntev lossis cov kev qhia tshwj xeeb, nws yuav siv sijhawm 70–90 hnub.
Vim muaj cov nqi raw khoom siab, lub Hoobkas tsis tshua muaj cov khoom tiav hauv Tshuag; kev tsim khoom feem ntau yog ua los ntawm kev ua -rau- xaj xaj.
