17-4PH 630 Stainless Hlau Sheet Phaj

Hom 630 stainless hlau yog dab tsi?

17-4PH stainless hlau (UNS S17400), tseem hu ua Hom 630, yog chromium-nickel-tooj ​​liab nag lossis daus-hardened martensitic stainless hlau nrog siab zog thiab hardness thiab zoo corrosion kuj. cov

17-4PH stainless hlau phaj kub kho

Kev daws teeb meem: cua sov ntawm 1020 ~ 1060 degree, ua raws li qhov txias txias. Cov qauv tom qab kev daws teeb meem yog feem ntau quenched martensite + residual austenite + ib qho me me ntawm ferrite. Tom qab kev laus kev kho mob, nplua thiab dispersed ntxiv dag zog rau theem yog precipitated nyob rau hauv lub alloy, zoo txhim kho lub zog thiab hardness ntawm lub alloy. cov

630 stainless hlau phaj daim ntawv thov thaj chaw

Aerospace: siv los tsim cov khoom siv dav hlau thiab cov cav cav. cov

Petrochemical: siv los tsim cov kav dej, li qub thiab cov reactors nyob rau hauv qhov kub thiab txias. cov

Marine engineering: siv los tsim offshore platforms, nkoj thiab cov khoom siv dhia dej, thiab lwm yam.

630 Martensitic stainless hlau phaj tshuaj muaj pes tsawg leeg

Carbon: Tsawg dua lossis sib npaug rau 0.07%
Manganese: Tsawg dua lossis sib npaug rau 1.00%
Silicon: Tsawg dua lossis sib npaug rau 1.00%
Chromium: 15.00 ~ 17.50%
Nickel: 3.0~5.0%
Phosphorus: Tsawg dua lossis sib npaug rau 0.04%
Sulfur: Tsawg dua lossis sib npaug rau 0.03%
tooj liab: 3.0~5.0%
Niobium + Tantalum: 0.15 ~ 0.45%.

630 stainless hlau mechanical zog:
Qhov ceev: kwv yees li 7.75 g / cm3
Cov cua kub tshwj xeeb: 0.11 BTU / lb- degree F @ 70 degree F (460 J / kg- degree @ 20 degree)
Modulus ntawm elasticity: 28.5 x 10 ^ 6 psi (196 GPa)
Thermal conductivity: 10.6 BTU-hauv / ft² - hr- degree F (18.3 W / m- degree) ntawm 212 degree F (100 degree)

Vim li cas thiaj xaiv GNEE

GNEE muaj kaum ob 8-22 nti txias kos duab chav tsev ntau lawm kab thiab txhawb nqa pickling, annealing thiab tsis siv neeg sib tsoo khoom. Kev tsim khoom siv lub sijhawm tiag tiag hauv online cov txheej txheem tso saib thiab taug qab qhov system kom ua tau zoo kom lub sijhawm tsim khoom thiab zoo. Lub peev xwm tsim tau txhua xyoo yog li 20, 000 tons.

Tiv tauj peb tam sim no rau kev kwv yees dawb. info@gneestainless.com

Q: Peb puas tuaj yeem tuaj xyuas koj lub Hoobkas?
A: Zoo siab txais tos. Thaum peb muaj koj lub sijhawm, peb yuav npaj pab pawg muag khoom los ua raws li koj qhov xwm txheej.
Q: Koj puas tuaj yeem muab kev pabcuam OEM / ODM?
A: Yog. Thov koj xav tiv tauj peb kom paub meej ntxiv kev sib tham.

Q.Dab tsi yog 1.4542 stainless hlau sib npaug?
A.630 stainless hlau yog ib qho ntawm cov qib stainless hlau tshiab tshaj plaws nrhiav tau nyob rau xyoo 1960. Raws li EN tus qauv, qib no yog sau ua 1.4542 lossis X5CrNiCuNb16-4 lossis 17-4 PH.

Cim npe nrov: 17-4ph 630 stainless hlau ntawv phaj, Tuam Tshoj 17-4ph 630 stainless hlau ntawv phaj manufacturers, hoobkas
