GENERAL PROPERTIES
Stainless hlau qib 301 yog ib qho uas feem ntau muaj austenitic stainless nrog zoo corrosion kuj thiab elevated carbon kom cia txias ua hauj lwm rau ntau yam tempers. Nws tuaj yeem tau txais hauv 1/4 nyuaj, 1/2 nyuaj, thiab tag nrho nyuaj.
Qauv: S30100
APPLICATIONS:
Lub zog siab thiab zoo heev corrosion kuj ua rau Hom 301 Stainless Hlau pab tau rau ntau yam kev siv. Cov kev siv ib txwm muaj xws li:
aircraft structural qhov chaw
trailer lub cev
cov khoom siv
architectural thiab automotive ntug
cov khoom siv vov tsev
conveyor siv
ntau yam kev siv tshuab.
Standard:
ASTM / ASME: UNS S30200
EURONORM: X 12 CrNi 17 7
PIB: 1.4310
RESISTANCE
CORROSION RESISTANCE
Kev ua haujlwm zoo hauv cov ntawv thov uas cuam tshuam rau sab nraud rau cov mob me me corrosive ntawm ambient kub.
Resistant sab nraum zoov, kev lag luam, marine, thiab tshuaj lom neeg ib puag ncig
susceptible to carbide nag lossis daus thaum vuam, uas txwv tsis pub nws siv nyob rau hauv ib co kev siv
Zoo ib yam li kev ua haujlwm ntawm Stainless hlau qib 304
HEAT RESISTANCE
Muaj peev xwm nthuav tawm tsis tu ncua yam tsis muaj qhov ntsuas qhov ntsuas siab tshaj plaws ntawm 1600 degree F (871 degree).
Qhov kub siab tshaj plaws yog txog 1450 degree F (788 degree), rau kev sib cuam tshuam
Muaj qhov hnyav oxidation nce ntawm 10mg / cm 2 hauv 1, 000 teev, nyob rau hauv qhov kub thiab txias tshaj 1600 degree F (871 degree ).
Tshuaj muaj pes tsawg leeg
Chemical Composition (wt%) txwv raws li teev hauv ASTM A240 thiab ASME SA240 *
| Element | 301 |
| Cov pa roj carbon | 0.15 |
| Chromium | 16.0-18.0 |
| Nickel | 6.0-8.0 |
| Manganese | 2.00 |
| Silicon | 1.00 |
| Nitrogen | 0.10 |
| Phosphorus | 0.045 |
| Sulfur | 0.030 |
* Qhov siab tshaj plaws, tshwj tsis yog muaj ntau yam qhia
Cov lus nug? Tiv tauj peb!
Mechanical Properties
Cov cuab yeej cuab tam rau cov khoom annealed raws li tau teev tseg hauv ASTM A240 thiab ASME SA240
| Khoom | 301 |
| Yield zog, min. (ksi) | 30 |
| Tensile zog, min. (ksi) | 75 |
| Elongation, min. (%) | 40 |
| Hardness, max. (Rb) | 95 |
Cov cuab yeej cuab yeej cuab tam rau cov khoom ua haujlwm txias ua haujlwm raws li tau teev tseg hauv ASTM A666
| Qhov xwm txheej | Yield zog (ksi) min. |
Tensile zog (ksi) min. |
Elongation % min. ua 2in. | |
| <0.015 in. | Ntau dua lossis sib npaug rau 0.015 hauv. | |||
| ¼ Nyuaj | 75 | 125 | 25 | 25 |
| ½ Nyhav | 110 | 150 | 15 | 18 |
| ¾ Hard | 135 | 175 | 10 | 12 |
| Full Hard | 140 | 185 | 8 | 9 |
Lub cev muaj zog
Lub cev muaj zog rau hom 301 stainless hlau
| Khoom | 301 |
| Ceev, lb/in3 | 0.285 |
| Modulus ntawm Elasticity, psi | 28.0 x 106 |
| Coefficient ntawm Thermal Expansion, 68-212˚F, /˚F | 9.2 x 10-6 |
| Thermal conductivity, Btu/ft hr ˚F | 9.4 |
| Tshwj xeeb kub, Btu/lb ˚F | 0.12 |
| Hluav taws xob tiv thaiv, Microohm-hauv | 27.4 |
